Seagate SkyHawk surveillance 10TB HDD

Hard Drives by Application: Which Is Best for You?

Designed for NVR (network video recorders) and AI-enabled NVR systems, the 10TB SkyHawk AI 7200 rpm SATA III 3.5" Internal Surveillance HDD from Seagate is well-suited for units with 16 or more drive bays. Engineered for 24/7 workloads, or 8760 operational hours per year, this SkyHawk AI drive supports up to 64 HD cameras and 32 additional AI streams, or 16 AI channels. Seagate's ImagePerfect AI technology helps to deliver zero dropped frames, while high reliability is backed by a workload rate of 550TB per year. Additionally, SkyHawk Health Management helps protect your surveillance storage by focusing on prevention, intervention, and recovery options. Should you use this drive in a RAID, integrated RAID RapidRebuild technology helps provide faster volume rebuilds.

Seagate built this SkyHawk AI drive with storage capacity of 10TB and a 3.5" form factor, plus a SATA III 6 Gb/s interface, a 256MB cache, and a rotational speed of 7200 rpm, all of which help to ensure uninterrupted data transfers with a sustained rate of up to 245 MB/s. Data reliability is further enhanced by 300,000 load/unload cycles, a 2 million hour MTBF, 1 per 1015 non-recoverable read errors per bits read, and an AFR (annualized failure rate) of 0.44%.

General Features

ImagePerfect AI Firmware

Provides improved image integrity alongside additional AI workload support in always-on, AI-enabled surveillance systems.

Designed to Support an Additional 32 AI Streams

This SkyHawk AI drive will support an additional 32 AI streams, while simultaneously recording footage from up to 64 HD cameras.

Built to Handle Heavy Surveillance Workloads

Designed and built to handle heavy surveillance workloads in traditional video recording and advanced video analytic environments, this SkyHawk AI drive has an endurance rating of 550TB per year and can withstand greater workloads than standard surveillance drives.

Advanced Vibration Management

Advanced vibration management delivers improved and sustained performance in NVR systems with 16 or more bays.

SkyHawk Health Management

SkyHawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options. Included is RAID RapidRebuild, which helps provides faster volume rebuilds. Contact your Seagate sales rep for further information.

Improved Reliability

Not only is reliability improved, but the total cost of ownership is reduced, thanks to a 2 million hour MTBF rating and a limited 3-year warranty.

Data Protection

An optional 2-year Rescue Data Recovery Services plan provides access to Seagate's secure data recovery labs. Contact your Seagate sales rep for further information.

UPC: 763649150474

In the Box

• Seagate 10TB SkyHawk AI 7200 rpm SATA III 3.5" Internal Surveillance HDD (Retail)

• Limited 3-Year Manufacturer Warranty

Seagate AI Internal HDD Specs

Storage CapacityTotal: 10 TB SATA III (6 Gb/s) 3.5" HDD (7200 rpm)Read SpeedMaximum: 245 MB/sWrite SpeedMaximum: 245 MB/sBuffer256 MB

HDD Specs

Heads10Areal Density1215 Gb/in²Disk Sector Format512n

Reliability / Data Integrity

Annualized Failure Rate (AFR)0.44 %EncryptionNoneLoad/Unload Cycles300,000Mean Time Between Failures (MTBF)2.0 Million HoursNon-Recoverable Read Errors per Bits Read1 in 1015

Electrical

Power Draw7.76 W (Idle)
10.09 W (Active)
0.96 W (Standby)Supported Voltage5 VDC, 12 VDC

Environmental

Operating Shock70 G / 2.0 msStorage Shock300 G / 2.0 msOperating Vibration1.04 G / 10 to 500 Hz

General

Dimensions5.78 x 4.01 x 1.02" / 146.81 x 101.85 x 25.91 mmWeight1.5 lb / 670 g

Packaging Info

Package Weight1.9 lbBox Dimensions (LxWxH)8.9 x 6.1 x 3"
